MICROSCANNER ENGLISH - 4
The Keypad
When turned on, MICROSCANNER will flash the
LCD power-up test and then resume the test
mode that was last executed. MICROSCANNER
will turn off automatically when no cable is
detected and no key has been used for 10
minutes.
Press ▲ ▼ to quickly change pairs or adjust
values. The ▲ ▼ keys are only active if the
indicators are shown on the display
Operating Mode
Press MODE to select the desired test. The
available modes are: WIREMAP - OFFICE
IDENTIFIER - LENGTH - TONER
Calibration Mode
+
Turn the MICROSCANNER OFF, then hold the
MODE key down while pressing the ON key to
start 'Calibrate' mode. Use MICROSCANNER to
calibrate cable lengths of more than 50 feet (15
meters) and up to 1500 feet (457 meters.)
