Microzone C7-MINI - Standard Receiver Function Analysis; Receiver Connections and Signals; Frequency Alignment Procedure

DIGITAL PROPORTIONAL R/CSYSTEM
www.microzone.cn
2.4GHz
FHSS
STANDARD RECEIVER FUNCTION ANALYSIS
MC8RE-V2
1 external voltage input
External
voltage
input
(S)signal
(+)positive
electrode
(-)negative
electrode
Contact frequency alignment
After the receiver is powered
on, press the touch button to
turn on the power switch of
the remote control, and the
frequency matching is
successful
7 PWM signal
External antenna
(-)negative
electrode
External input DC 6V power supply
For indoor testing
1 SBUS signal
