26 Chapter 5: Patching
PRO6 Control Centre
Quick Reference Guide
• Repeating for the other devices.
• Closing the device’s configuration window.
>> To open the configuration window of a device
Click the device’s spanner button.
>> To set up/change the configuration of an I/O device
1 Open the configuration window of the I/O device you want to configure (see “To
open the configuration window of a device” on page 26).
2 Select the I/O device from the drop-down list at the
top of the configuration window.
3 Select the card/channel you want to
configure/change, from the
drop-down list at the upper-right
corner of the configuration window.
For example, the “Analogue In
Card”.
4 In a channel, configure the parameters. For example, in
channel “In1”, adjust the gain and switch the +48V phantom
voltage on (shown right).
5 Repeat step 4 for the other channels in the card.
6 Repeat step 3 to step 5 for the other cards.
7 If you want, you can configure other I/O devices by
repeating step 2 to step 6. Otherwise, click OK (bottom of
configuration window) to save the configuration changes and
close the window.
