46 Chapter 6: Basic Operation
PRO6 Control Centre
Quick Reference Guide
Simple routing to master stereo outputs
The following shows you how to obtain audio. Before proceeding with this operation,
make sure nothing is muted and master faders are up.
>> To obtain audio
Do one of the following:
• Press the ST (stereo) button of
an input fast strip.
• Press the ST (stereo) button of
a channel strip.
Scene and show management (automation)
Automation allows you to manage show files and the scenes within the shows. This is
all done via the Automation screen (a GUI menu option). Figure 11 (below) shows
typical Automation screen displays before (left) and after a show is loaded.
Figure 11: Typical Automation screen displays
>> To access the Automation screen
Do one of the following:
• At the GUI, choose home
AutomationAutomation.
• In the primary navigation zone, press the automation/filing screen access button.
