The PAN controls the group pla-
cement within the master stereo-
mix and has a constant power
law i. e. -3dB at the centre posi-
tion and 0dB or off at either ex-
treme setting.
The MAS switch connects the
post fader group signals to the
stereo master bus via the pan
control.
The SIGNAL (-16dBu) PEAK
(+16dBu) display monitors the
signal level of the group bus.
The GROUP faders give conti-
nuous adjstment of the sub group
output levels from +10dB to off.
The SOLO switch sends the
group signal to the PFL / mono
and AFL / stereo busses. If the
switch is engaged the mon 1/2
meters are automatically used
for solo metering
15
