Midas XL48 User Manual

25
Operator Manual
9. Signal Flow Diagram
in 1
-20dB
gain
low pass high pass
(output 1)
outputs 1-8 (x2)
(5-8 at 96k) (1-4 at 96k)
analogue outputs 1-8
(output 1)
(output 1)
AES3 outputs 1-8 (x2)
input
word
clock
75R
output
Digital Format
Conversion
ADC
(input 1)
parallel analogue inputs 1-8
Each input channel is routed directly to its respective output. However, when the
unit is congured to run at 88.2kHz or 96kHz the two ADAT output connectors are
shared due to the bandwidth limitation of the interface.
midasconsoles.com

Midas XL48 Specifications

General

Brand	Midas
Model	XL48
Category	Amplifier
Language	English
