V. PS638E & G OVEN KEY SPARE PARTS
ITEM QTY P/N DESCRIPTION
1 1 74453 Digital Display, Programmed
2 1 65756 Motor, Conveyor Drive (74106)
3 1 71927 Dual-Mode Conveyor Control Board
4 1 74097 VFD Inverter, 2 HP (230VAC Input)
5 1 61186 Power Supply, 24VDC, 40W
6 1 71421 Hamlin Rotation Hall Effect Sensor
7a 1 36451 Small Cooling Fan for Right Control Compartment
7b 1 97525 Large Cooling Fan for Center Rear of Oven
n/s 1 65858 Small Cooling Fan Filter (6” square)
n/s 1 73226 Large Cooling Fan Filter (9” square)
8 2 63909/63910 Door Switches, Interlock / Momentary
9 1 57288 Blower Motor, 2 HP
10 1 61602 Ignition Module (Gas Only)
11 1 59450 Maxitrol Modulating Gas Valve (Gas Only)
12 1 59465 Dual Solenoid Combination Valve (Gas Only)
13 1 33983 Hi Limit Thermostat
n/s 1 71040 High Limit Reset Button
n/s 1 71041 High Limit Light
14 1 32108 Transformer, 240 primary / 24 secondary
15a 1 64998 PLC
15b 1 58668 Thermocouple Module
15c 1 73188 Dual Output Module
16 1 33984 Thermocouple (3 per oven)
17 1 68371 Bearing, Dodge 5/8
18 1 71771 Relay, DPDT 24VDC Coil
19a 2 44914 208/240V SS Power Controllers
19b 2 44568 380/416V SS Power Controllers,
20 1 70788 Single Rod Igniter
21 1 62282 Ignition Cable
22a 1 72847 Blower Wheel, Right = CW
22b 1 72873 Blower Wheel, Left = CCW
n/s 2 71815 Blower Shaft
23 1 50517 Serpentine Blower Belt
24a 1 74124 Heater, 27kW, 208VAC Specific
24b 1 74125 Heater, 27kW, 240VAC Specific
24c 1 74126 Heater, 18kW, 380VAC Specific
24c 1 73656 Heater, 27kW, 380VAC Specific
25 1 72209 Magic Photo Eye (optional)
n/s 1 61147 Magic Photo Eye Lens (optional)
26 1 60452 Contactor (Electric Only)
27a
27b
1
1
44914
44568
Power Relay, 208-240V (Electric Only)
Power Relay, 380-415V (Electric Only)
28 1 50794 Relay, 240VAC Coil
29 1 72730 Magnetic Ring
n/s 3 72737 In-Shot Burner (Gas Only)
