Midea Aqua Tempto Power Series

MCAC-ATSM-2014-09 Aqua tempo power series tropical air-cooled scroll chiller 50Hz
73
No.
Part Name
Qty
No.
Part Name
Qty
17
Outlet pipe ass'y I of condenser
3
69.9
Transformer
2
18
Inputting pipe ass'y of D unit evaporator
1
69.10
A Terminal Block
1
18.1
Electronic expansion valve
1
69.11
Wire joint,11p
1
18.2
Strainer
2
69.12
Wire joint, 1P
3
19
Four-way valve ass'y II
1
69.13
Wire joint,4p
1
20
Pipe support VI
1
69.14
Terminal block
7
21
Cover of wire casing III
1
70
Reinforcing board II
3
22
Wire casing III
1
71
Three-phase asynchronous motor
6
23
Installation base plate of condenser
16
72
Back support board of electric box
1
24
Outlet pipe ass'y II of condenser
1
73
Pipe support V
3
25
Wire casing I
1
74
Seal plate condenser
8
26
Cover of wire casing I
1
75
Motor
2
27
Shell-tube heat exchanger
1
76
Axial fan
8
28
Installation base welding parts of compressor
4
77
Motor bracket bonding parts
16
29
Inclined support II
1
78
Part B condenser
4
30
Pipe support I
1
79
A machine Condenser Parts
4
31
Pipe support II
2
80
Condenser fixed plate ass'y
4
32
Grille fixed board I
4
81
Condenser fixed plate ass'y
4
33
Front grille
8
82
Welding parts water tray
4
34
Fixed board II of grille
2
83
Cover II of electrical box
1
35
Compressor
8
84
Cover I of electrical box
1
36
Plastic washer
50
85
Support board of electrical box
2
37
Liquid separator
4
86
Output pipe of evaporator
1
38
Bottom column
4
87
Output pipe ass'y of evaporator(A)
1
39
Beam
2
88
Output pipe ass'y of evaporator(B)
1
40
Front Panel
5
89
Output pipe ass'y of evaporator(C)
1
41
Wire casing
1
90
Output pipe ass'y of evaporator(D)
1
42
Cover of wire casing II
1
91
Suction pipe ass'y of compressor
4
43
Fixed board of drainage
8
92
Suction pipe III
4
44
Connection parts of roof beams
4
93
Oil balance pipe ass'y I
4
45
Panel fasteners II
8
94
Reinforcing board
1
46
Inclined support I
1
95
Refrigerant
60
47
Wire support
3
96
Oil balance pipe ass'y II
4
48
Wiring bridge
3
97
Four-way valve coil
4
49
I sealed connector condenser
4
98
Compressor wire joint
4
50
Condenser sealed connector II
4
99
Electronic expansion valve coil
4
51
Network Rail fixed plate II
2
100
Total water temperature mouth components
1
52
About the protective screen
4
101
Target flow-volume controller
1
53
Upper beam
2
102
Electrical heating belt compression
8
54
Roof rack beam welding parts
3
