EN-17
ACCESSORIES
REMOVING THE DOOR FROM OVEN (OPTIONAL)
Disassembly of oven door components
1. To remove the door, open the door to the
maximum angle.Then pull the buckle at the
door hinge backward.
2. Close the door to an angle approximately 30°.
Hold the door with one hand on each side. Lift
up and slowly pull the door out from the oven.
3. Open the door rotation bracket assembly, refer
the action in the following picture.
4.
Lift up the door outer glass and pull it out, then
take the door middle glass out in the same way.
WARNING:
process.
WARNING:
The hinge springs could loose, causing personal
WARNING:
handle.
