DISASSEMBLY INSTRUCTIONS SIZES 18K (208−230V) (CONT)
2 Fan
assembly
How to remove the fan
assembly.
1) After removing the
panel plate using
section 1, remove the
hex nut securing the
fan then remove the
fan.
2) After removing the top
cover, release the
hooks then open the
electronic control box
cover.
ƻ
1
ƻ
2
T3
,
T4
,
T5 sensor
Motor wire Electronic
expansion valve
Compressor wire
4 way valve wire
Electric pipe heater and Crankcase
electric heater
