Midea DLCERAH12AAJ

32808001101 61
Specifications subject to change without notice.
DISASSEMBLY INSTRUCTIONS SIZES 18K (208−230V) (CONT)
2) Pull out the two blue
wires connected to the
four way valve.
3) Remove the
connectors of the
condenser coil temp.
sensor (T3),outdoor
ambient temp. sensor
(T4) and discharge
temp. sensor (T5).
4) Disconnect the
electronic expansion
valve wire.
ƻ
3
ƻ
3
ƻ
4
ƻ
2
