P.23
4.Overview of main parts
4.8 Absorber
Midea drum washing machine uses the advanced
absorber to damp the vibration by drum tub kit
when this machine wash and spin. Absorber uses
friction damping to achieve its function of damping
vibration. Thanks to its similar the piston-type
structure, the sponge in the cylindrical plastic inner
wall of cylinder and the cavernous metal rod
contacts close, the cylinder rod can sliding along
the axial and longitudinal, which generate a certain
damping force. There is special cavernous damping
oil in the sponge, which is the main part to achieve shock absorber. The damping force
keeps constant and its direction is opposite toroid running. Absorber pin is used to
connect left/right lower reinforce to absorber, the absorber and tub as well.
4.9 Drum tub assembly
4.9.1 Rear tub kit
As a container for water, the tub capability of this washing machine is not only effects
it's rated washing capacity but also decides its rated consumption of water. That is, at the
same condition of water level, the radial dimension and the lengthways dimension of its
tub have larger, the more its rated consumption of water.
The tub material of Midea washing machine is well property and improved PP which is
high intensity, heat-resistant and high rigid. As a good heat guard, PP ensures this
machine save power and improves its washing performance in a sense.
This structure, which is divide tub kit into front tub kit and rear tub kit, improves the
assembly performance of this machine and enhance its airproof.
4.OVERVIEW OF MAIN COMPONENTS
