Midea H2 Series - Page 38

Midea AC Fan Coil Unit
37
MKH2(3)-800-R3
EWT
ΔT
Indoor temperature (D.B.)
16
18
20
22
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
[°C]
[°C]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
35
5
6.05
1.05
17.01
5.29
0.92
13.42
4.52
0.78
10.2
3.73
0.65
7.36
8
5.3
0.57
6.07
4.48
0.49
4.59
3.63
0.39
3.22
2.72
0.29
1.98
10
4.64
0.4
3.36
3.73
0.32
2.33
1.91
0.17
0.6
1.31
0.11
0.38
12
3.57
0.26
1.51
1.95
0.14
0.49
1.41
0.1
0.35
0.79
0.06
0.2
15
1.83
0.11
0.38
1.24
0.07
0.26
-
-
-
-
-
-
40
5
8.01
1.39
26.8
7.21
1.25
22.44
6.44
1.11
18.27
5.68
0.98
14.65
8
7.3
0.79
10.27
6.53
0.71
8.43
5.73
0.62
6.69
4.92
0.53
5.17
10
6.79
0.59
6.17
5.97
0.52
4.95
5.13
0.44
3.84
4.27
0.37
2.82
12
6.18
0.44
3.88
5.31
0.38
3.02
4.4
0.32
2.21
3.21
0.23
1.22
15
4.95
0.28
1.86
2.76
0.16
0.56
2.1
0.12
0.39
1.54
0.09
0.29
45
5
9.92
1.72
38.09
9.13
1.58
32.84
8.2
1.39
43.91
7.58
1.31
23.82
8
9.27
1
15.02
8.49
0.92
12.86
7.69
0.83
10.87
6.89
0.75
9.02
10
8.81
0.76
9.39
8.01
0.69
7.97
7.21
0.62
6.67
6.42
0.55
5.44
12
8.3
0.6
6.25
7.48
0.54
5.23
6.66
0.48
4.28
5.8
0.42
3.4
15
7.38
0.43
3.53
6.5
0.37
2.85
5.59
0.32
2.22
4.62
0.27
1.61
50
5
11.84
2.05
50.5
11.04
1.91
44.7
10.26
1.77
39.26
9.46
1.64
34.29
8
11.24
1.22
20.54
10.43
1.13
17.98
9.64
1.04
15.68
8.85
0.96
13.52
10
10.81
0.94
13.07
9.99
0.87
11.44
9.18
0.8
9.9
8.4
0.73
8.47
12
10.32
0.74
8.84
9.49
0.69
7.68
8.65
0.63
6.59
7.89
0.57
5.57
15
9.54
0.55
5.32
8.69
0.5
4.54
7.86
0.45
3.81
7
0.4
3.14
55
5
13.75
2.39
64.99
12.95
2.26
58.91
12.16
2.12
52.7
11.37
1.98
46.86
8
13.14
1.43
26.58
12.34
1.34
23.8
11.55
1.26
21.3
10.79
1.18
18.83
10
12.73
1.11
17.09
11.92
1.04
15.25
11.14
0.97
13.52
10.36
0.9
11.89
12
12.29
0.89
11.81
11.49
0.83
10.45
10.69
0.77
9.22
9.87
0.72
8.06
15
11.59
0.67
7.28
10.78
0.62
6.41
9.94
0.58
5.6
9.12
0.53
4.83
60
5
15.68
2.71
79.89
14.85
2.59
73.31
14.05
2.45
66.47
13.25
2.3
59.5
8
15.11
1.65
33.21
14.29
1.55
30.08
13.5
1.47
27.1
12.66
1.38
24.38
10
14.72
1.28
21.51
13.9
1.21
19.48
13.07
1.14
17.56
12.27
1.07
15.74
12
14.3
1.04
14.94
13.48
0.98
13.49
12.64
0.92
12.12
11.87
0.86
10.81
15
13.62
0.79
9.38
12.76
0.74
8.43
11.97
0.69
7.52
11.16
0.65
6.66
65
5
17.59
3.05
96.7
16.77
2.91
88.75
15.96
2.78
81.93
15.15
2.63
74.2
8
17.03
1.86
40.26
16.22
1.77
36.92
15.41
1.68
33.73
14.62
1.59
30.7
10
16.65
1.45
26.17
15.83
1.38
23.96
15.02
1.31
21.85
14.23
1.24
19.92
12
16.25
1.18
18.3
15.43
1.12
16.71
14.62
1.06
15.21
13.81
1
13.77
15
15.61
0.9
11.63
14.78
0.86
10.58
13.97
0.81
9.59
13.15
0.76
8.64
Abbreviations:
Δt: Temperature Difference (℃)
TH: Total Heating Capacity (kW)
WF: Water Flow (m
3
/h)
WPD: Water Pressure Drop (kPa)
