Midea H2 Series User Manual

Midea AC Fan Coil Unit
4
5. Specifications
Model
MKH2-150-R3
MKH3-150-R3
MKH2-150-R4
MKH3-150-R4
MKH2-250-R3
MKH3-250-R3
MKH2-250-R4
MKH3-250-R4
Power supply
V/Ph/Hz
220-240/1/50
Air flow (H/M/L)
m
3
/h
255/165/142
255/192/139
400/273/180
425/284/184
CFM
150/97/84
150/113/82
235/161/106
250/167/109
External static pressure
Pa
H2:0/H3:12
Cooling
Total Capacity (H/M/L)
kW
1.65/1.22/1.09
2.25/1.85/1.46
2.65/2.02/1.40
3.05/2.26/1.63
Water flow rate (H/M/L)
L/h
283/209/186
386/317/249
454/346/240
523/387/280
Water pressure drop (H/M/L)
kPa
22.11/13.10/10.35
49.29/33.22/21.74
18.19/11.29/5.53
33.66/19.73/10.61
Heating
Capacity (H/M/L)
kW
1.85/1.29/1.13
2.35/1.87/1.40
3.05/2.24/1.52
3.15/2.09/1.38
Water flow rate (H/M/L)
L/h
317/222/194
403/320/240
523/384/260
540/357/237
Water pressure drop (H/M/L)
kPa
16.18/8.79/7.11
36.51/24.61/16.1
17.00/9.95/5.26
25.84/13.93/6.77
Power input (H/M/L)
W
35/17/14
40/24/15
47/26/14
47/26/14
Rated current
A
0.15/0.07/0.06
0.17/0.10/0.07
0.20/0.11/0.06
0.20/0.11/0.06
Sound power level
(H/M/L)
dB(A)
47/35/34
53/47/39
46/37/31
47/38/32
Fan motor
Type
AC fan motor
Quantity
1
1
1
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
1
1
2
2
Coil
Row
3
4
3
4
Max. working pressure
MPa
1.6
1.6
1.6
1.6
Diameter
mm
Φ7.94
Φ7.94
Φ7.94
Φ7.94
H2 Body
Net dimensions (W×H×D)
mm
495×200×790
495×200×790
495×200×1020
495×200×1020
Packing size (W×H×D)
mm
595×300×895
595×300×895
595×300×1125
595×300×1125
Net weight
kg
16.3
16.7
20.0
20.8
Gross weight
kg
21.8
22.2
26.0
26.8
H3 Body
Net dimensions (W×H×D)
mm
455×200×607
455×200×607
455×200×837
455×200×837
Packing size (W×H×D)
mm
555×255×755
555×255×755
555×255×985
555×255×985
Net weight
kg
11.6
12.0
13.9
14.8
Gross weight
kg
15.9
16.3
19.4
20.3
Water inlet/outlet pipe
inch
G3/4
G3/4
G3/4
G3/4
Drain pipe
mm
ODΦ18.5
ODΦ18.5
ODΦ18.5
ODΦ18.5
Notes:
1. H: High fan speed; M: Medium fan speed; L: Low fan speed.
2. Cooling conditions: Entering water 7℃, leaving water 12℃, Entering air temperature 27℃ DB/19℃ WB.
3. Heating conditions: Entering water 45℃, leaving water 40℃, Entering air temperature 20℃ DB/15℃ WB.
4. Noise is tested in a reverberation chamber.

Midea H2 Series Specifications
