Midea H2 Series User Manual

Midea AC Fan Coil Unit
6
Model
MKH2-700-R3
MKH3-700-R3
MKH2-700-R4
MKH3-700-R4
MKH2-800-R3
MKH3-800-R3
MKH2-800-R4
MKH3-800-R4
Power supply
V/Ph/Hz
220-240/1/50
Air flow (H/M/L)
m
3
/h
1190/855/555
1150/885/591
1300/1088/782
1300/1132/836
CFM
700/503/327
677/521/348
766/641/461
766/667/492
External static pressure
Pa
H2:0/H3:12
Cooling
Total Capacity (H/M/L)
kW
6.00/5.03/3.71
6.75/5.80/4.24
7.35/6.51/5.15
8.25/7.52/5.87
Water flow rate (H/M/L)
L/h
1029/862/636
1157/995/727
1260/1116/884
1414/1289/1007
Water pressure drop (H/M/L)
kPa
62.13/42.69/24.44
46.5/33.73/18.66
48.82/39.82/25.03
74.76/63.56/40.28
Heating
Capacity (H/M/L)
kW
6.15/4.92/3.49
7.15/5.81/4.04
8.20/7.09/5.46
8.50/7.60/5.72
Water flow rate (H/M/L)
L/h
1054/844/598
1226/996/692
1406/1216/937
1457/1302/981
Water pressure drop (H/M/L)
kPa
60.74/40.46/22.16
44.27/30.11/15.39
46.11/35.24/20.65
65.06/49.83/30.28
Power input (H/M/L)
W
123/98/68
110/89/64
123/109/83
118/104/82
Rated current
A
0.53/0.42/0.30
0.48/0.39/0.28
0.53/0.47/0.36
0.51/0.45/0.36
Sound power level
(H/M/L)
dB(A)
63/56/45
62/56/46
62/58/50
62/58/50
Fan motor
Type
AC fan motor
Quantity
1
1
1
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
3
3
3
3
Coil
Row
3
4
3
4
Max. working pressure
MPa
1.6
1.6
1.6
1.6
Diameter
mm
Φ7.94
Φ7.94
Φ7.94
Φ7.94
H2 Body
Net dimensions (W×H×D)
mm
495×200×1360
495×200×1360
591×200×1360
591×200×1360
Packing size (W×H×D)
mm
595×300×1465
595×300×1465
695×300×1465
695×300×1465
Net weight
kg
27.3
28.5
31.7
34.0
Gross weight
kg
34.8
36.0
40.2
42.0
H3 Body
Net dimensions (W×H×D)
mm
455×200×1177
455×200×1177
550×200×1177
550×200×1177
Packing size (W×H×D)
mm
555×255×1325
555×255×1325
650×255×1325
650×255×1325
Net weight
kg
20.5
21.7
24.0
25.2
Gross weight
kg
27.3
28.5
31.1
32.3
Water inlet/outlet pipe
inch
G3/4
G3/4
G3/4
G3/4
Drain pipe
mm
ODΦ18.5
ODΦ18.5
ODΦ18.5
ODΦ18.5
Notes:
1. H: High fan speed; M: Medium fan speed; L: Low fan speed.
2. Cooling conditions: Entering water 7℃, leaving water 12℃, Entering air temperature 27℃ DB/19℃ WB.
3. Heating conditions: Entering water 45℃, leaving water 40℃, Entering air temperature 20℃ DB/15℃ WB.
4. Noise is tested in a reverberation chamber.
