All accessories in the freezer chamber should be
dismantled before removing the air duct components.
1） Remove 2 screws on the cover plate of the
refrigerator air duct using a cross screwdriver;
2） Pull out the connector terminal of the fan motor;
3） pull out the cap of the refrigerator upper air duct,
and then remove the 2 screw of the refrigerator
upper air duct components
4） Pull out the connector
1） Tear off the kraft paper tape
2） Remove the fan motor from the air duct component
3） Replace
the fan motor, the reverse operation for assembly
