Midea HS-455LWEN-W1

20
1） Remove the air duct components in freezer chamber.
2） Disconnect all connectors.
3） Remove the welding on inlet and outlet tubes.
Ambient temperature sensor
Before remove the sensor, the freezer duct assembly
should be removed
1） Remove the air duct assembly from the freezer.
2） Remove the sensor.
Ambient temperature sensor
None
Freezer sensor
None
8.6Compressor case
Rear cover and compressor case
None
Condenser fan moto
None
No rear cover
None
Terminal box of the compressor
None
Standby condenser
None
Piping system in the compressor case
1.Compressor
5.Dry filter
