Midea HS-625FWEN - Page 26

Service Manual_2020-V1.0
26
2）Slowly tilt the refrigerator forward, relying on the wall or
a solid enough object, leaving space to facilitate the
operation. For safety, it should be carried by someone to
prevent its falling.
3）Cut off the compressor pipeline.-❶Cut off the process
pipeline.-❷Cut off the low-pressure muffler.-❸Cut off
the high-pressure exhaust pipe.
4-1）Remove the screws(for some models)
-Two screws outside
-One screw inside
4-2）Remove the metal clamp(for some models)
-Disassembly the metal clamp that is fix the electric
appliance shield
5）Remove the clipping strip
Slowly pull it out
