6）Remove the protective cover
-Pry the protective cover slowly from the upper part,
-Pull it out and remove it.
7）Remove the starter and protector
Unplug the starter and protector (you can use a
screwdriver to pry it slowly)
8）Loosen the screw of the compressor bottom plate,
remove the floor together with the compressor from the
box.
9）Use the wrench to remove the bolts by
steps❹❺❻❼, replace the compressor and reverse
process can complete installation.
