Specifications
Page 12
Indoor model MSABAU-09HRFN8-QRD0GW MSABBU-12HRFNX-QRD0GW MSABDU-18HRFNX-QRD0GW MSABEU-24HRFNX-QRD0GW
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Cooling
Capacity Btu/h 9000 12000 18000 25000
Input W 24 24 34 62
Current A 0.11 0.11 0.15 0.28
Heating
Capacity Btu/h 10000 13000 19000 26000
Input W 24 24 34 62
current A 0.11 0.11 0.15 0.28
Indoor fan
motor
Model ZKFP-20-8-6-7 ZKFP-20-8-6-7 ZKFP-30-8-3 ZKFP-58-8-1
Input W 50.0 50.0 36 58
Capacitor uF / / / /
Speed(Hi/Mi/Lo) r/min 1150/850/700 1100/1000/700 1100/800/700 1100/900/700
Indoor coil
a.Number of rows 3.0 2 2 2 2
b.Tube pitch(a)x row
pitch(b)
mm 21x13.37 21x13.37 21x13.37 21x13.37
c.Fin spacing mm 1.3 1.3 1.2 1.3
d.Fin type (code) Hydrophilic aluminum Hydrophilic aluminium Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.
and type
mm Φ7,Inner groove tube Φ7,innergroove tube Φ7,innergroove tube Φ7,innergroove tube
f.Coil length x height
x width
mm
525x84x13.37+525x105x26.74
+525x105x26.74
605x210x26.74+605x84x26.74
750x210x26.74+
750x126x26.74
820x210x26.74+
820x126x26.74
g.Number of circuits 2 2 4 4
Indoor air flow (Hi/Mi/Lo) m3/h 416/309/230 515/459/294 750/505/420 1020/830/640
Indoor sound pressure level (Hi) dB(A) 39/23/20 38/22/21 41/28/20 46/30/26
Indoor sound power level (Hi) dB(A) 54 56 58 62
Indoor unit
Dimension(W*D*H) mm 722x187x290 802x189x297 965x215x319 1080x226x335
Packing (W*D*H) mm 790x270x375 875x285x380 1045x305x410 1155x415x320
Net/Gross weight Kg 7.3/9.7 8.2/10.7 10.8/14.1 12.9/16.5
Design pressure MPa 4.3/1.7 4.3/1.7 4.3/1.7 4.3/1.7
Refrigerant
piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8")
Controller
Wired
Control
Remote Control Remote Control Remote Control Remote Control
Operation temperature °C 17~30 17~30 17~30 17~30
Room tem-
perature
Cooling °C 17~32 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30 0~30
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
