Specifications
Page 10
Indoor model MSAFBU-07HRDNX-QRD0GW MSAFBU-09HRDN8-QRD0GW MSAFBU-12HRDN8-QRD0GW
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Cooling
Capacity Btu/h 7000 9000 12000
Input W 20 20 20
Current A 0.09 0.09 0.09
Heating
Capacity Btu/h 8000 10000 13000
Input W 20 20 20
current A 0.09 0.09 0.09
Indoor fan motor
Model YKFG-13-4-38L YKFG-13-4-38L YKFG-13-4-38L
Input W 40 40 40
Capacitor uF 1.2 1.2 1.2
Speed(Hi/Mi/Lo) r/min 1030/850/700 1030/850/700 1130/950/750
Indoor coil
a.Number of rows 3.0 2.0 2.0 2.0
b.Tube pitch(a)x row pitch(b) mm 19.5x11.6 19.5x11.6 19.5x11.6
c.Fin spacing mm 1.2 1.2 1.2
d.Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
e.Tube outside dia.and type mm Φ5,innergroove tube Φ5,innergroove tube Φ5,innergroove tube
f.Coil length x height x width mm 595x273x23.2 595x273x23.2 595x273x23.2
g.Number of circuits 4 4 4
Indoor air flow (Hi/Mi/Lo) m3/h 520/460/340 520/460/340 600/500/360
Indoor sound pressure level (Hi) dB(A) 40/30/26/21 40/30/26/21 40/34/26/22
Indoor sound power level (Hi) dB(A) 54 53 53
Indoor unit
Dimension(W*D*H) mm 805x194x285 805x194x285 805x194x285
Packing (W*D*H) mm 870x270x360 870x270x360 870x270x360
Net/Gross weight Kg 7.5/9.7 7.5/9.7 7.5/9.7
Design pressure MPa 4.3/1.7 4.3/1.7 4.3/1.7
Refrigerant piping Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8")
Controller
Wired
Control
Remote Control Remote Control Remote Control
Operation temperature °C 17~30 17~30 17~30
Room tempera-
ture
Cooling °C 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
