Specifications
Page 11
Indoor model MSAFCU-18HRFN8-QRD0GW MSAFDU-24HRFN8-QRD0GW
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50
Cooling
Capacity Btu/h 18000 24000
Input W 34 62
Current A 0.15 0.28
Heating
Capacity Btu/h 19000 25000
Input W 34 62
current A 0.15 0.28
Indoor fan motor
Model ZKFP-30-8-3 ZKFP-58-8-1
Input W 36 58.0
Capacitor uF / /
Speed(Hi/Mi/Lo) r/min 1130 / 900 / 800 1150 / 1000 / 850
Indoor coil
a.Number of rows 3.0 2.0 2.0
b.Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
c.Fin spacing mm 1.2 1.3
d.Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
e.Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube
f.Coil length x height x width mm 750x294x26.74 780x315x26.74
g.Number of circuits 3 4
Indoor air flow (Hi/Mi/Lo) m3/h 840/680/540 980/817/662
Indoor sound pressure level (Hi) dB(A) 44/37/30/25 44.5/42/34.5/28
Indoor sound power level (Hi) dB(A) 55 59
Indoor unit
Dimension(W*D*H) mm 957x213x302 1040x220x327
Packing (W*D*H) mm 1035x295x380 1120x405x310
Net/Gross weight Kg 10/13 12.3/15.8
Design pressure MPa 4.3/1.7 4.3/1.7
Refrigerant piping Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.9(3/8"/5/8")
Controller Wired Control Remote control Remote control
Operation temperature °C 17~30 17~30
Room temperature
Cooling °C 17~32 17~32
Heating °C 0~30 0~30
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
