Midea MAE50-S1102GPS Service Manual

Service manual for portable washer Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 11 －
4. TROUBLE SHOOTING
4.1 Test mode by Control
Note: Before entering the test mode, you should empty the machine so that there is no
water left in the tub. You can run a Spin Only cycle or operate as following steps to get all
water out. Then make sure all parts are in their original position for check running.
Step 1：Lay the drain hose down to insert the end of the hose into an
outfall on floor.
Step 2: Remove the Back Panel from the unit.
Step 3: Find the Drain Valve and pull the bar and keep pulling as the
arrow direction as right figure.
Step 4: Wait for the water to be drained out.
Now, the unit is ready for test check.

Midea MAE50-S1102GPS Specifications

General

Style	top load
Color	white
Washer Capacity	1.6 cubic feet
Max Spin Speed	800 revolutions per minute
Internal Heater	no
Control Panel	digital
Delay Start / End	yes
Child Lock	no
Steam	no
Annual Energy Consumption	290 kilowatt hours
Voltage	120 volts

Weight and Dimensions

Depth	20.25 inches
Height	36.25 inches
Width	20.69 inches
Net Weight	68 pounds
