Under any circum st ances, m ake sure the ceram ic cooker hob is well ventilat ed
and t he air inlet and outlet are not blocked. Ensure the ceram ic cooker hob is in
good work st ate. As shown below
Note: The safety dist ance bet ween the hotplate and the cupboard above
the hotplat e should be at least 760m m .
A(mm) B(mm) C(mm) D E
760 50 mini 30 mini Air intake Air exit 10 mm
Be fore locating t he fix ing bra cket s
The unit should be placed on a stable, sm ooth surface ( use t he packaging). Do
not apply force onto t he controls protruding from t he hob.
Fix t he hob on the work surface by screw four brackets on the bot t om of hob
(see pict ure) after inst allation.
A B C D
screw bracket Screw hole base
