Midea MC-SU30-RN1L Technical & Service Manual

Aqua Tempo Super II Series DC Inverter Air-cooled chiller unit (50Hz) MCAC-ATSM-201704
9
5.Specifications
Model MC-SU30-RN1L MC-SU60-RN1L
Cooling Capacity kW
27 55
Heating Capacity kW
31 61
Power input
Cooling kW
10.8 22.0
Cooling rated current A
16.7 33.9
Heating kW
10.5 20.3
Heating rated current A
16.2 31.3
EER kW / kW 2.5 2.5
SEER kW / kW 4.41 4.2
COP kW / kW 2.95 3.0
SCOP kW / kW 4.01 3.85
Power supply V/Ph/Hz 380-415/3/50 380-415/3/50
Power supply
Manual switch A 50 100
Fuse A 36 70
Max. Input consumption kW
11.67 23.86
Max current A
18 36.8
Compressor
Type Rotary Rotary
Brand Mitsubishi Electric Mitsubishi Electric
Quantity Piece
1 2
Capacity kW 20.1±5% 20.1±5%
Input kW 6.27±5% 6.27±5%
Rate load Amps.(RLA) A 17.7 17.7
Demagnetizing current A 68.9 68.9
Refrigerant oil ml
2300 2300x2
Refrigerant
Type
R410A R410A
Refrigerant control
EXV+ Capillary EXV+ Capillary
Weight kg
10.5 17
Condenser
(Air side)
Type Finned tube Finned tube
Number of rows
2 3
Quantity of fan motor Pieces
1 2
Air flow ×10
3
m
3
/h 12.5
24
Fan motor rated current
A
3.1 7.0
Fan motor input kW 0.45 1.2
Evaporator
(Water side)
Type
Plate Plate
Water pressure drop kPa 60
80
Volume L
2.44
5.17
Water inlet/outlet pipeline
inside normal diameter
mm
DN40 DN50
Water flow m
3
/h
5
9.8
Max. design pressure MPa 1.0 1.0
Water pipe connection type Clasp connection Clasp connection
Dimension
Net(W×H×D) mm
1870×1175×1000 2220×1325×1055
Packing size(W×H×D) mm
1910×1225×1035 2250×1370×1090
Weight
Net weight kg
300 480
Operation weight kg
310 490
