Aqua Tempo Super II Series DC Inverter Air-cooled chiller unit (50Hz) MCAC-ATSM-201704
7
4.3.2 Backup functions
When unit is failed
If master unit fails, all the units will stop.
If one slave unit fails, this unit will stop but the others will keep running.
When the master unit fails, any of the slave one can be set as the master unit by manual setting the
address switch.
When unit is under protection
If master unit’s protection happens, this unit will stop but the others will keep running.
If slave unit’s protection happens, this unit will stop but the others will keep running.
Except for some protections happen (detail protection please refer to protection codes)
4.4 Flexible installation
4.4.1 Built-in hydraulic module (customization option)
Built-in hydraulic module products can be customized. The modules are fully integrated and built-in
expansion tank, plate heat exchanger, water circulating pump, etc. It saves you much installation space and
cost.
Option1: Built-in water circulating pump
Option2: Built-in water circulating pump and 100L expansion tank
Note:1. Option1 pump head 19m on MC-SU30-RN1L and 15m on MC-SU60-RN1L.
2. Option2 is only available on MC-SU30-RN1L.
Slave
Maste
