87
7
Test report
CONdebug
Connect to detector
8
Fuse
Fuse 1
Fuse T30A/250V
9
SW1
SW1
Digital display button
10
DSP1
DSP1
Digital display
11
CN23
CN23
CN23 reserve
12
CN14
CN14
Connect to exhaust temperature sensor
13
N-OUT
CN5
Connect to the terminal (208-230V AC)
L-OUT
CN6
14
CN7
CN7
Connect to inverter driver
15
LOW / HIGH
CN9
Connect to high and low pressure sensor
16
T3 / T4
CN8
Connect to T3 / T4 temperature sensor
17
Fuse
Fuse 2
Fuse 5A/250V
18
L
CN22
Connect to the 4-way valve. When the 4-way is ON, output 208-230V
AC.
N
CN3
19
CN42
CN42
Connect to motor capacitor
CN41
CN41
20
AC Fan
CN43
Connect to AC fan motor
21
Electronic
Expansion
valve
CN20
connect to Electric Expansion Valve A
CN21
connect to Electric Expansion Valve B
CN17
connect to Electric Expansion Valve C
CN18
connect to Electric Expansion Valve D
CN19
connect to Electric Expansion Valve E
