MCAC-UTSM-2012--05 R407C MCCU Technical Manual
37
11.2 MCCU-10CN2
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1 Motor 1 202400440401 11.4 Wire joint, 5p 1 202301450039
2 Motor bracket assy’ 1 201275590020 11.5 AC contactor 1 202300850046
3 Rear net 1 201148700000 11.6 Main control board assy’ 1 201347890001
4 Condenser assy’ 1 201547010621 11.7 Transformer 1 202300900551
5 Compressor 1 201400710500 11.8 Wire joint,4p 1 202301450003
6 Big handle 1 201148200005 12 Base assy’ 1 201248700125
7 Valve plate 1 201248790001 13
Front right clapboard
assy’
1 201248700056
8 High pressure valve assy’ 1 201675590096 14 Front net assy’ 1 201248700055
8.1 Strainer 1 201600900075 15 Front panel 1 201248700052
8.2 High pressure valve 1 201600740620 16 Net clamp 10 201135110801
9 Suction pipe assy’ 1 201675590101 17
Rear right clapboard
assy’
1 201248700053
9.1 Pressure controller 1 202301820031 18
Sealing parts for
condenser
1 201245420701
9.2 Low pressure valve 1 201600720415 19 Partition board assy’ 1 201248700006
9.3 Strainer 1 201600900014 20 Left holder 1 201248700050
10 Discharge pipe assy’ 1 201675590098 21 Rear Supporter 1 201245420620
10.1 Pressure controller 1 202301820025 22 Top cover assy’ 1 201248700051
11 E-part box assy’ 1 203347890002 23 Axial flow fan 1 201195000001
11.1 Capacitor 1 202300320025 24 Temp. sensor assy’ 1 202440500002
11.2 Electric installation board 1 201275590077 25 Discharge temp sensor 1 202301610024
11.3 Wire joint 1 202301450117 26 Temp sensor 1 202445410003
