Midea MCCU-7CN2 - Page 38

R407C CCU Technical Manual MCAC-UTSM-2012-05
38
11.3 MCCU-14CN2
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1
Motor
1 202400440401 11.5
AC contactor
1 202300850046
2
Motor bracket assy’
1 201275590020 11.6
Main control board assy’
1 201347890001
3
Rear net
1 201148700000 11.7
Wire joint,4p
1 202301450003
4
Condenser assy’
1 201575690018 11.8
Transformer
1 202300900551
5
Compressor
1 201400710470 12
Base assy’
1 201248700125
6
Big handle
1 201148200005 13
Front right clapboard assy’
1 201248700056
7
Valve plate
1 201248790001 14
Front net assy’
1 201248700055
8
High pressure valve assy’
1 201675790354 15
Front panel
1 201248700052
8.1
Low pressure valve
1 201600720098 16
Net clamp
10 201135110801
9
Suction pipe assy’
1 201675590547 17
Rear right clapboard assy’
1 201248700053
9.1
Pressure controller
1 202301820031 18
Sealing parts for condenser
1 201245420701
9.2
Low pressure valve
1 201600720415 19
Partition board assy’
1 201248700006
9.3
Strainer
1 201600900014 20
Left holder
1 201248700050
10
Discharge pipe assy’
1 201675790356 21
Rear Supporter
1 201245420620
10.1
Pressure controller
1 202301820025 22
Top cover assy’
1 201248700051
10.2
Muffler
1 201601000031 23
Axial flow fan
1 201195000001
11
E-part box assy’
1 203347890002 24
Temp.sensor assy’
1 202440500002
11.1
Capacitor
1 202300320025 25
Discharge temp sensor
1 202301610024
11.2
Electric installation board
1 201275590077 26
Drainage cover
1 201148790000
11.3
Wire joint
2 202301450117 27
Compressor wire joint assy’
1 202445400405
11.4
Wire joint, 5p
1 202301450039 - - - -
