Midea MCCU-7CN2 - Page 39

MCAC-UTSM-2012--05 R407C MCCU Technical Manual
39
11.4 MCCU-16CN2
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1
Condenser assy’
1 201575890056 19
High pressure valve assy’
1 201675890381
2
Motor bracket assy’
1 201275600085 19.1
Low pressure valve
1 201600720098
3.1
Motor
1 202400400185 20
Discharge pipe assy’
1 201675890383
3.2
Motor
1 202400400186 20.1
Pipe joint
1 201601200001
4
Front panel
1 201275600092 20.2
Pressure controller
1 202301820025
5
Axial flow fan
2 201100300102 21
Handle
2 201148700009
6
Front net assy’
2 201275890056 22
E-part box assy’
1 203375890099
7
Front-right panel assy’
1 201275890054 22.1
Electric installation board
1 201275600094
8
Valve plate
1 201248790001 22.2
Wire joint
1 202301450101
9
Rear-right panel
1 201275600089 22.3
Wire joint
2 202301450117
10
Separator
1 201601100060 22.4
AC contactor
1 202300850045
11
Partition board assy’
1 201275600090 22.5
Wire joint,4p
1 202301450003
12
Compressor
1 201400710460 22.6
Transformer
1 202300900083
13
Base
1 201275600095 22.7
Motor capacitor
2 202401100407
14
Rear supporter
1 201275600086 22.8
Main control board assy’
1 201375890082
15
Top cover
1 201275600087 23
Discharge temp sensor
1 202301610500
16
Rear-left supporting
board
1 201275600088 24
Room temp sensor assy’
1 202301300196
17
Low pressure valve assy’
1 201675600222 25
Temp sensor assy’
1 202450200331
17.1
Low pressure valve
1 201600720414 26
Compressor wire joint
assy’
1 202445400405
18
Suction pipe assy’
1 201675600220 27
Drainage cover
1 201148790000
18.1
Pressure controller
1 202301820026 28
Big handle
1 201157390002
