5.DISASSEMBLY INFORMATION FOR THE PRODUCT
- 13 -
2-2. Remove the power line
2-3. Remove the filter
3. remove the door component (including the door hinge)
(1) remove the screws fixed door hinge;
(2) take down the door component and hinge.
3-1. remove the door hinge,front door and back door frame
4. Remove the inner tub assy
(1) Remove the reinforced plate;
(2) take out the belt from the motor shaft ;
(3) removed the screws which is fixed drum kit and the
automatic thermostat;
(4) pull out the terminal connected wire with heating
pipe;
(5) take out the drum kit and the belt.
