16
ITEM PICTURE
Unscrew 4 screws on the side
brackets (left and right).
Unscrew 1 screw on the back cover.
Unscrew 2 screws on the back cover.
Unscrew 1 screw on side plate and
unplug all terminals.
Remove all of the screws on the
back cover and take it off.
3 Disassembling Ways of Main Parts
