Midea MDC100-CH21B/B05E-US User Manual

17
ITEM PICTURE
Unscrew the
nut(M10) and remove
the impeller.
Unscrew 5 screws on the cabinet
cover back
.
Lift up
pulley of the motor and
remove the belt.
Separate the tub assembly.
Unscrew 4 screws on the bearing
house assembly
and remove the
bearing cover.
3 Disassembling Ways of Main Parts
