Midea MDC100-CH21B/B05E-US User Manual

23
ITEM PICTURE
Remove 2
screws and take off the
choke
.
Take off the internal wire assembly
from base
assembly.
Remove all screws from
the cover of
heat
exchangers and take it off.
Unscrew the
nuts of compressor and
remove
the heat exchangers(2
persons to lift the unit)
Remove the tension spring.
3 Disassembling Ways of Main Parts
