Midea MDC100-CH21B/B05E-US User Manual

24
ITEM PICTURE
Remove 2 screws and take off the
motor.
Unscrew 3
screws and remove the
blower collet of compressor.
Remove 1 screw and take off the fan.
Pull out NTC.
Remove the condenser clap plate.
Remove two foot screws.
3 Disassembling Ways of Main Parts
