Instructions
Method 2 - Po
wer Supply Cord
IMPORTANT:
•
The po
wer cord and connections must comply with the National
Electrical Code, Section 422 and/or local codes and ordinances.
Recommended cord length is 54" min. and 64" max.
•
A mating 3 pr
ong, ground-type wall receptacle is required in a cabinet
next to the dishwasher opening.
•
A pow
er cord kit part #BK500 is available for purchase from an
authorized parts dealer.
1. Drill a 1
" (3.8 cm) hole in the cabinet rear or side
. Preferred and
Optional locations are shown in the following graphic.
2. Smooth edges of hole for power cord.
Wood Cabinet - Sand edges of hole until smooth.
Metal Cabinet - Cover edges of hole with grommet (not provided).
3. Attach power cord to dishwasher before moving it into the opening.
See “Connect Power Supply” section for proper installation technique.
ba
a
Pref
erred Locations
b
Optional Loca
tions
WARNING
Electrical Shock Hazard
•
Plug into a gr
ounded 3 prong outlet.
•
Do not remo
ve the ground prong from the power cord
plug.
•
Do not use an adapter
.
•
Do not use an ext
ension cord.
•
Failur
e to do so can result in death, fire or electrical
shock.
PREPARE T
O CONNECT WATER LINE
NOTE:
Routing the water line through the left side of cabinet opening will
make water connection easier.
1. Drill a
" (1.3 cm) hole in the cabinet side, r
ear or floor. Preferred and
optional locations are shown in the following graphic.
2. Measure to determine the overall length of copper tubing required for
the water line.
IMPORTANT: Slowly feed copper tubing through hole in cabinet.
Copper tubing bends and kinks easily, so handle the tubing gently.
