11
(5).Malfunction display
When the malfunction happened at the same time, the priority is P1>T2>T1
7.5 Set humidity operation
(1).In this operation, the range of work is 35%RH-85%RH.
(2).The fan keeps the same speed as last mode.
(3).The action of compressor in this operation is like the below graph show:
7.6 Continually dehumidify operation
In this operation, the compressor and fan will be working continually unless there is a water full
protection or sensor fault protection. The Setting humidity operation is unapplied.
8 Basic test procedure
8.1 Defective compressor
Compressors are single phase, 220-240volt, depending on the model unit. All compressor motors
are permanent split capacitor type using only a running capacitor across the start and run terminal.
All compressors are internally spring mounted and externally mounted on rubber isolators.
8.1.1 Compressor wiring test
