The wash stops
Programme selection
1 Install the washing
machine
3 Measure out the
detergent
7 Plug the power supply
8 Select the desired
programme
5 Put down (hang up)
the drain pipe
4 Close the
machine door
9 Press the
[start/pause] key
11
When the wash stops, the buzzer will buzz continuously for 6 times and
then the power will be automatically cut off.
Turn off the water tap.
Although the power can be cut off automatically, the power plug must be pull
out for the safety.
1
Press the POWER button.
3
press the start/pause key.
2
Select the proper water level and other attached functions.
2 Load the laundry
Instruction of the STANDARD program
Instruction to single wash procedure
Steps in details
1.Press the power switch.
2.According to the washing amount choose the proper water level.
3.Press START/PAUSE button.
12
1.Close the lid of the door when machine is running, otherwise, it will automatically
stop working during spin process and send out abnormal warning.
2.The washer will not work when the filled water does not reach the set water level.
1.[Standard] wash program is the easiest, most convenient and most common washing
program. When the user press the power switch and then press [Start/Pause] button,
the standard washing program will start to work.
2.When the washer start to work, the digital tube show the remain time. The indicator
light which stand for remaining time is flickering.
1.User may freely select any single procedure, or any combination of procedures
among WASH, RINSE and SPIN according to the actual requirements. It is only
required to turn off any one or two of these three indicators that not needed by the
user. And keep the indicator be on showing the process needed by the user.
2.Single wash -- after switching on the power, turn off RINSE and SPIN two indicators
by pressing these two keys. The operation for single rinse and single spin is similar.
3.Single wash-spin – after switching on the power, turn off RINSE indicator by pressing
that key. The operation for single rinse-spin and single wash-rinse is similar.
NOTICE
！
Quick start
The main wash
Use the cleaning solution for twice
1. Put the laundry in the first batch and wash powder and press “Function” button to set
single “wash” to run.
2. Take out the laundry in the first batch after hearing the buzzing sound.
3. put in the laundry in the second batch, and run “ Wash”, “Rinse”, “Spin”.
4. Take out the laundry in the second batch after hearing the buzzing sound.
5. Put in the laundry in the first batch and press “ Function” button to run “Rinse” and “Spin”.
6 Turn on water supply

Midea MFW-1250MV2 Specifications

General

Drum capacity	12 kg
Delay start (max)	48 h
Spin-drying class	-
Maximum spin speed	- RPM
Noise level (spin)	- dB
Delayed start timer	Yes
Load balancing system	No
Package weight	53000 g
Drum volume	95 L
Control type	Touch
Loading type	Front-load
Drum material	Stainless steel
Outlet hose length	3 m
Appliance placement	Freestanding
Connected load	600 W
AC input voltage	240 V
AC input frequency	50 Hz
Energy consumption washing per cycle	- kWh

Weight and Dimensions

Depth	625 mm
Width	601 mm
Height	1015 mm
Weight	45000 g
