1
CAUTION
Precautions before reading the installation manual.
1. PRECAUTIONS
Read this user manual carefully before installing the equipment.
The air conditioner must be installed by professional technicians.
When installing the indoor unit and its accessory pipes, adhere to
this user’s manual as far as possible.
Inspect and make sure the piping and cabling are correct before
powering on the air conditioner.
This information may change with the update of this machine, and
no further notice will be given for such change.
WARNING
The safety precautions listed here are divided into two categories. In
either case, important safety information is listed which must be read
carefully.
After completing the installation, make sure that the unit operates
properly during the start-up operation. Please instruct the customer
on how to operate the unit and keep it maintained.Also, inform
customers that they should store this installation manual along with
the owner's manual for future reference.
indoor unit, and direct the transmitting part of the remote
controller to the receiver of the indoor unit.
The remote controller should be over 1m away from the
television or sound box.
Do not place the remote controller at a moist place, near the
heat sources such as stove, or expose it directly in the sunlight.
Ensure correct positive and negative poles when loading the
batteries.
Decide the correct way of conveying the equipment.
Try to transport this equipment with the original package.
If the a ir conditioner needs to be installed on a metal part of the
building, electric insulation must be performed, and the
installation must meet the relevant technical standards of electric
devices.
The appliance must be installed 2.3m above floor.
The appliance shall not be installed in the laundry.
Before obtaining access to terminals, all supply circuits
must be disconnected.
The appliance must be positioned so that the plug is
accessible.
The enclosure of the appliance shall be marked by word, or
by symbols, with the direction of the fluid flow.
If the supply cord is damaged, it must be replaced by the
manufacture or its service agent or a similarly qualified
person in order to avoid a hazard.
An all-pole disconnection switch having a contact
separation of at least 3mm in all poles should be
connected in fixed wiring.
Power wire of air conditioner should not intersect with
lightning-proof ground lead。
Ensure a safety distance between Air conditioner device
and lightning-proof device should be more than 3 meters
In the area that is vulnerable to lightning and rain, we
suggest install a proper lightning protector in front of the
power wire of air conditioner equipment.
Failure to observe a warning may result in death.
CAUTION
Failure to observe a caution may result in injury or damage
to the equipment.
Install the unit where enough space of installation and
maintenance is available.
Install the unit where the ceiling is horizontal and enough for
bearing the weight of the indoor unit.
Install the unit where the air inlet and outlet are not baffled and
are the least affected by external air.
Install the unit where the supply air flow can be sent to all parts
in the room.
Install the unit where it is easy to lead out the connective pipe
and the drain pipe.
Install the unit where no heat is emitted from a heat source
directly.
Installing the equipment in any of the following places may lead
to faults of the equipment (if that is inevitable, consult the
supplier):
CONTENTS PAGE
PRECAUTIONS........................................................................................1
ACCESSORIES ...................................................................................... 2
INSTALLATING INDOOR UNIT ...............................................................2
INSTALLATING OUTDOOR UNIT............................................................4
ELECTRIC CONNECTION.........................................................................8
ELECTRIC WIRE DIAGRAM.....................................................................9
SETTING STATIC PRESSURE................................................................10
STATIC-CURVE.....................................................................................10
INDOOR UNIT MAINTENANCE..............................................................10
CONSTRUCTION AND VENTILATION PIPELINE DESIGN SCHEME.........12
TRIAL RUN ..........................................................................................13
WARNING
Do not throw or slam the remote controller.
Operate the remote controller within the receiving scope of the
