M thermal Mono
202005 41
Part 3 - Installation and Field Settings
Figure 3-2.8: Parallel connect the two units or above
Figure 3-2.9: Parallel connect the front with rear sides
>600
>3000
>300
>3000 >1000
>6000
>4000 >300
Midea CAC Confidential
