Specifications
Page 5
1. Electrical Wiring Diagrams
1.1 Indoor unit
Abbreviation Paraphrase
Y/G Yellow-Green Conductor
ION Positive and Negative Ion Generator
CAP Capacitor
PLASMA Electronic Dust Collector
L LIVE
N NEUTRAL
Heater The Electric Heating Belt of Indoor Unit
T1 Indoor Room Temperature
T2 Coil Temperature of Indoor Heat Exchanger
MSMBB-09HRFN1-BT0W, MSMBB-12HRFN1-BT0W, MSMBB-09HRFN1-MW0W, MSMBB-12HRFN1-MU0W,
MSMBD-18HRFN1-MT0W, MSMBD-23HRFN1-MT0W
