19
Safety and
Precautions
Installation
Requirements
Installation
Instructions
Dryer Use
Dryer Care
Troublesho
o
ting
STEP 3 Level the dryer
Adjust the leveling feet only as much as necessary to level the dryer.
Extending the leveling feet more than necessary can cause the dryer
to vibrate.
•
The dryer frame is grounded to the neutral conductor at the terminal
block. A 4-WIRE SYSTEM CONNECTION is required for new or
remodeled construction,mobile homes, or if local codes do not permit
grounding through neutral conductor.
If the 4-wire system is used, the dryer frame cannot be grounded to the
neutral conductor at the terminal block. Refer to the “Electric
requirements” section on page 14 for 3-WIRE or 4-WIRE SYSTEM
CONNECTIONS.
Remove the terminal block cover plate.
Insert the power cord with a UL-listed strain relief through the hose
provided in the cabinet near the terminal block.
A strain relief must be used.
Do not loosen the nuts already installed on the terminal block. Be sure
they are tight.
Use a 3/8" (1cm) deep well socket.
To ensure that the dryer provides the optimal drying performance, it must
be leveled. To minimize vibration, noise, and unwanted movement, the
floor must be a perfectly level, solid surface.
•
Level
loosen
lock
Adjustable leg
