Disassembly of oven door components
1.
2.
3.
4.
To remove the door, open the door to the
maximum angle. Then pull the buckle at
the door hinge backward.
Close the door to an angle approximately 30°.
Hold the door with one hand on each side.
Lift up and slowly pull the door out from the oven.
Open the door rotation bracket assembly, refer
the action in the following picture.
Lift up the door outer glass and pull it out, then
take the door middle glass out in the same way.
WARNING:
Don't forcibly pulled out the door and prevent the
glass breakage during the dismantling process.
WARNING:
The hinge springs could loose, causing personal injury.
WARNING:
Do not lift or carry the oven door by the door handle.
30˚
REMOVING THE DOOR FROM OVEN (OPTIONAL)
