GD Midea Refrigeration Equipment Co. Ltd Service manual for K portable Series
2
24 hours on/off mode time setting.
Both temperature mode display
Separate motor for indoor and outdoor system.
Multiple uses: dehumidifying and cloth drying.
Low temperature Drying operation.
There are four casters on the bottom for easy
movement.
Only one exhaust pipe, which makes the A/C
easier to use.
Remote-controlled or gentle-touch keys for easy
and comfortable use.
Compressors of famous brands are adopted for
reliability and low noise.
The heating system uses PTC electrical heater
and will not be affected by ambient temperature,
which saves energy.
Suitable for local cooling and heating.
Condenser shower and large volume tank design.
Long time to pour the tank.
Directly drainage available.
1.4 CONTROL LOCATIONS
For cooling only with electric heater models:
For cooling only models:
Remote receiver.
Timer ON button. Push this button to set the
Timer On time.
Timer OFF button. Push this button to set the
Timer Off time.
Timer ON/OFF lamp.
o
F
Fahrenheit temperature display. When
Fahrenheit temperature display mode is
selected.
o
C
Celsius temperature display. When Celsius
temperature display mode is selected.
Temperature setting up. Push this button to
set temperature setting up.
Temperature setting down. Push this button to
set temperature setting down.
Cooling operation lamp.
Drying operation lamp.
Fan only operation lamp.
Electric heating operation lamp.
Mode setting button. Push this button to select
the operation mode: Cool, Dry, Fan only and
Heat
High fan speed lamp.
Med fan speed lamp.
Low fan speed lamp.
Fan speed setting button. Push this button to
select fan speed: High, Med and Low.
Power button. Push this button to start the
unit.
Water full alarm lamp
Power lamp
