Midea MSV1-07CR-QB8F - Page 11

Service manual
- 7 -
MSV-09CR-QB8F MSV-09HR-QB8FMSV-09CR-NC2F MSV-09HR-NC2F
Ph-V-Hz
1, 220-240V~, 50Hz 1, 220-240V~, 50Hz 1, 220-230V~, 60Hz 1, 220-230V~, 60Hz
Capacity Btu/h 9000 9000 9000 9000
Input W 940 940 820 820
Rated current A 4.2 4.2 3.7 3.7
EER Btu/w.h
9.55 9.55 10.9 10.9
Capacity Btu/h
___________
10000
___________
10000
Input W
___________
980
___________
910
Rated current A
___________
4.4
___________
4.1
COP W/W
___________
10.2
___________
10.9
A 6.3 6.3 6 6
A 19.8 19.8 26 26
Model 2P18S225ANK 2P18S225ANK 2P14S236A1E 2P14S236A1J
Type Rotary
Rotary
Rotary
Rotary
Brand Matsushita Matsushita Matsushita Matsushita
Capacity Btu/h 9912 9912 9161 9195
Input W 970 970 845 850
Rated current(RLA) A 4.5 4.5 3.8 3.8
Locked rotor Amp(LRA)
A 19.8 19.8 26 26
Thermal protector External External External External
Capacitor uF 30 30 30 30
Refrigerant oil ml 350 350 270 350
Model
RPG20D RPG20D RPG13B RPG13B
Brand Welling Welling Welling Welling
Input W 32 32 32 32
Capacitor uF 1.2 1.2 1.2 1.2
Speed(hi/mi/lo) r/min 1040/900/800 1040/900/800 1040/900/800 1040/900/800
m3/h 550 550 550 550
dB(A) 38/35/32 38/35/32 38/35/32 38/35/32
Model
YDK24-6T YDK24-6T YDK25-6B YDK24-6FB
Brand Welling Welling Welling Welling
Input W
70 70 82.5 72
Capacitor uF
3 3 2.5 2.5
Speed r/min
850 850 950 830
m
3
/h
1800 1800 1800 1800
dB(A)
52
52
54
54
g 580 800 900 1000
MPa
2.6 2.6 2.6 2.6
Liquid side/ Gas side mm
Ф
6.35/
Ф
9.53
Ф
6.35/
Ф
9.53
Ф
6.35/
Ф
9.53
Ф
6.35/
Ф
9.53
Max. refrigerant pipe length
m 10 10 10 10
Max. difference in level
m 5 5 5 5
℃
17-30 17-30 17-30 17-30
℃
18-45 -7-45 18-45 -7-45
m
2
14-21 14-21 14-21 14-21
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R22
Design pressure
Refrigerant
piping
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Max. current
Starting current
Compressor
Indoor
fan motor
Model
Power supply
Cooling
Heating
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are
normally somewhat different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product
improvement.
