Service manual
- 8 -
MSV1-12CR-QB8FMSV1-12HR-QB8FMSV1-12CR-NC2FMSV1-12HR-NC2F
Ph-V-Hz
1, 220-240V~, 50Hz 1, 220-240V~, 50Hz 1, 220-230V~, 60Hz 1, 220-230V~, 60Hz
Capacity Btu/h 12000 12000 12000 12000
Input W 1260 1260 1100 1100
Rated current A 5.6 5.6 4.9 4.9
EER Btu/w.h 9.55 9.55 10.9 10.9
Capacity Btu/h ___________ 13000 ___________ 13000
Input W ___________ 1270 ___________ 1190
Rated current A ___________ 5.7 ___________ 5.3
COP W/W ___________ 10.2 ___________ 10.9
A 1.4 1.4 1.4 1.4
A 1700 1700 1500 1500
Model PH225X2C-4FT PH225X2C-4FT 2P19S236A1J 2P19S236A1J
Type Rotary Rotary Rotary Rotary
Brand GMCC GMCC Matsushita Matsushita
Capacity Btu/h 13197/13299 13197/13299 12659 12659
Input W 1250/1285 1250/1285 1165 1165
Rated current(RLA) A 5.7/5.5 5.7/5.5 5.2 5.2
Locked rotor Amp(LRA)
A 29.9/33 29.9/33 33 33
Thermal protector UP3RE0591-T56 UP3RE0591-T56 External External
Capacitor uF 35 35 30 30
Refrigerant oil ml 480 480 350 350
Model RPG20D RPG20D RPG13B RPG13B
Brand Welling Welling Welling Welling
Input W 32 32 32 32
Capacitor uF 1.5 1.5 1.2 1.2
Speed(hi/mi/lo) r/min 1260/1080/900 1260/1080/900 1260/1080/900 1260/1080/900
m3/h 650 650 650 650
dB(A) 42/39/36 42/39/36 42/39/36 42/39/36
Model YDK24-6 YDK24-6 YDK25-6B YDK25-6B
Brand Welling Welling Welling Welling
Input W 70 70 82.5 82.5
Capacitor uF 2.5 2.5 2.5 2.5
Speed r/min 850 850 950 950
m
3
/h
1800 1800 1800 1800
dB(A) 54 54 55 55
g 850 900 1020 1050
MPa 2.6 2.6 2.6 2.6
Liquid side/ Gas side mm Ф6.35/φ12.7 Ф6.35/φ12.7 Ф6.35/φ12.7 Ф6.35/φ12.7
Max. refrigerant pipe length
m 10 10 10 10
Max. difference in level
m 5 5 5 5
℃
17-30 17-30 17-30 17-30
℃
18-45 -7-45 18-45 -7-45
m
2
18-26 18-26 18-26 18-26
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R22
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are
normally somewhat different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product
improvement.
