HP set switch ENC1 definition list
Code
Name
Code
Indoor Unit
Capacity Value
FM
Fan motor
GM
Swinging motor
0
1800W(0.6HP)
DM
Water drainage pump
0
2200W(0.8HP)
CS
Water level switch
1
2800W(1.0HP)
PMV
Electronic expansion valve
2
3600W(1.2HP)
T1
Indoor temp. sensor
3
4500W(1.5HP)
T2
Mid-pipe temp. sensor of evaporator
4
5600W(2.0HP)
T2B
Outlet temp. sensor of evaporator
5
7100W(2.5HP)
XP1-3
Butt connection socket
6
8000W(3.0HP)
XS1-3
Butt connection socket
7
9000W(3.2HP)
TR
Power transformer
8
11200W(4.0HP)
9
14000W(5.0HP)
1
The E-heating component is optional, not for all models.
2
All dial code switches (include HP switch) cannot be adjusted by the user!
3
Power wire fixed screw must be fastened, otherwise may cause fire!
4
After air-conditioner installation and maintenance, put back the electric
control box cover, otherwise may cause fire and electric shock!
