Midea One-way Cassette Series

Four-way Cassette MCAC-VTSM-2017-01
61
2. Specifications
Model
MDV-D28Q4/N1-D
MDV-D36Q4/N1-D
MDV-D45Q4/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
2.8
3.6
4.5
Input
W
65
65
75
Rated current
A
0.41
0.41
0.41
Heating
Capacity
kW
3.2
4
5
Input
W
65
65
75
Rated current
A
0.41
0.41
0.41
Indoor fan motor
Model
YDK60-6F-3
Type
AC
Input (H/M/L)
W
62/57/47
62/57/47
65/59/49
Capacitor
uF
2.5
2.5
3
Speed (H/M/L)
r/min
540/490/420
540/490/420
610/540/460
Indoor coil
Number of rows
1
1
2
Tube pitch(a) × row
pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic Aluminum
Tube outside dia. and
type
mm
Ф7,Innergroove Tube
Coil length × height ×
width
mm
1930×168×13.37
1930×168×13.37
1961×168×26.74
Number of circuits
4
4
8
Indoor air flow (H/M/L)
m
3
/h
847/766/640
847/766/640
864/755/658
Sound pressure level (H/M/L)
dB(A)
42/38/35
42/38/35
42/38/35
Indoor unit
Dimension (W × H × D)
mm
904×230×840
Packing (W × H × D)
mm
955×260×955
Net/Gross weight
kg
24/28
24/28
26/30
Panel
Dimension (W × H × D)
mm
950×54.5×950
Packing (W × H × D)
mm
1035×90×1035
Net/Gross weight
kg
6/9
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Φ6.35
Gas pipe
mm
Φ12.7
Drain pipe
mm
ODФ32
Controller
Wireless remote controller
Notes:
1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB, 19°CWB, and outdoor
temperature:35°CDB, equivalent ref. piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB, outdoor temperature:
7°CDB, 6°CWB, and equivalent ref. Piping: 7.5m (horizontal)
