Midea One-way Cassette Series

MCAC-VTSM-2017-01 Two-way Cassette
28
Specifications
Model
MDV-D45Q2/N1
MDV-D56Q2/N1
MDV-D71Q2/N1
Power supply
220-240V-1ph-50Hz
Cooling
Capacity
kW
4.5
5.6
7.1
Input
W
92
108
154
Rated current
A
0.5
0.65
0.85
Heating
Capacity
kW
5
6.3
8
Input
W
92
108
154
Rated current
A
0.5
0.65
0.85
Indoor fan motor
Model
YSK58-4-1
YSK58-4
YSK91-4
Type
AC
Input
W
81
95
142
Capacitor
uF
2
3.5
3.5
Speed (H/M/L)
r/min
801/645/542
910/755/642
1159/1032/795
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic Aluminum
Tube outside dia. and type
mm
Ф7, Inner-groove Tube
Coil length × height × width
mm
882×210×26.74
Number of circuits
6
Indoor air flow (H/M/L)
m
3
/h
850/670/550
980/800/670
1200/1000/770
Sound pressure level (H/M/L)
dB(A)
39/35/30
39/35/30
44/40/34
Indoor unit
Dimension (W× H × D)
mm
1172×299×591
Packing (W×H×D)
mm
1355×400×675
Net/Gross weight
kg
36/44.5
Panel
Dimension (W× H ×D)
mm
1430×53×680
Packing (W×H×D)
mm
1525×130×765
Net/Gross weight
kg
10.5/15
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Φ6.35
Φ9.53
Φ9.53
Gas pipe
mm
Φ12.7
Φ15.9
Φ15.9
Drain pipe
mm
OD Ф32
Controller
Wireless remote controller
Notes:1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB,19°CWB,
outdoor temperature:35°CDB,equivalent ref. Piping: 7.5m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB,
outdoor temperature: 7°CDB,6°CWB,equivalent ref. Piping: 7.5m(horizontal)
