Midea One-way Cassette Series

Compact Four-way Cassette MCAC-VTSM-2017-01
45
Specifications
Model
MDV-D36Q4/N1-A3
MDV-D45Q4/N1-A3
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
3.6
4.5
Input
W
56
56
Rated current
A
0.25
0.25
Heating
Capacity
kW
4
5
Input
W
56
56
Rated current
A
0.25
0.25
Indoor fan motor
Model
YDK15-6P
Type
AC
Input
W
47
Capacitor
uF
1.5
Speed (H/M/L)
r/min
780/670/540
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.3
Fin type
Hydrophilic aluminium
Tube outside dia. and type
mm
Ф7
Inner groove tube
Coil length × height × width
mm
1310×210×26.74
Number of circuits
4
Indoor air flow (H/M/L)
m
3
/h
521/409/314
Sound pressure level (H/M/L)
dB(A)
42/36/29
Indoor unit
Dimension (W×H×D)
mm
570×260×570
Packing (W×H×D)
mm
675×285×675
Net/Gross weight
kg
18/22
Panel
Dimension (W×H×D)
mm
647×50×647
Packing (W×H×D)
mm
715×123×715
Net/Gross weight
kg
2.5/4.5
Refrigerant Type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Ф6.35
Gas pipe
mm
Ф12.7
Drain pipe
mm
ODФ25
Controller
Wireless remote controller
Notes:
1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB, 19°CWB, and outdoor
temperature:35°CDB, equivalent ref. piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB, outdoor temperature:
7°CDB, 6°CWB, and equivalent ref. Piping: 7.5m (horizontal)
